GPS 4G/WIFI 1080P CCTV CAMERA M91H

FOB Reference Price:Get Latest Price
$1,380.00 - $1,450.00 / Set | 1 Set/Sets (Min. Order)
Type:
IP Camera
Style:
PTZ camera
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
OEM
Model Number:
M91H
Sensor:
CMOS
Special Features:
Waterproof / Weatherproof
Technology:
Pan / Tilt / Zoom
Type:
Digital Camera
Industrial design:
Integrated industrial design
Security:
User password, Administrator password management
Input/output:
1 channel 1080p video input, 1 channel video output;1.0Vp-p, 75Ω
Compression:
H.265 High Profile Compression
Resolution:
1080p/720P/ adjustable
Storage:
Support 2pcs SD
Zoom:
20X/30X
IR Distance:
>60 meters
Supply Ability
Supply Ability:
1000 Set/Sets per Week
Packaging & Delivery
Packaging Details
Standard packing ( 8 sets / carton ) / OEM package.
Port
Shenzhen
Product Description

4G HD IR PTZ Camera is a professional HD IR PTZ camera integrated with record, HD video wireless transmit, audio ,talk and remote control. It adopts high speed processor hardware and embedded Linux system. The state of the art HD camera use the latest IT technologies, such as H.265 code, wireless transmitting technologies, remotely control etc. This powerful camera can be deployed on wireless and temporary outdoor surveillance application like police, traffic,concerts, or others.


Product Pictures

Key features

1. Industrial-grade and integrated design for reliable working on harsh environment
2. H.265 high profile compression
3. 360 degree PTZ 20X/30X, 200 preset , auto cruising
4. …..Built-in battery power supply(4-6 hours work) or external power
5. Support 2pcs SD card, each one up to 256G for record storage
6. 4G/WIFI transmit; multiple grade image quality transmitting option
7. GPS/BD/GLONASS global positioning
8. Powerful software platform including remote live, playback, broadcast, talk and more


Specification
Industrial design
Integrated industrial design
User interface
Support E-set,remote controller, remotely operation,
SD card ,etc to configure
Language
English,Chinese (option customized)
Security
User password, Administrator password management
Video &preview
Input/output
1 channel 1080p video input, 1 channel video output;1.0Vp-p, 75Ω
OSD
Overlays letters… like date /time into the video
Compression
H.265 High Profile Compression
Dual stream
Record with HD video and remotely live view with lower stream
preview
1 channel
Speed(frame rate)
PAL: 25fps, NTSC: 30fps
Resolution
1080p/720P/ adjustable
Image quality
High, middle, and low option
Video rate
720P:1024kbps/2048kbps/3072kbps/4096kbps/5120kbps
1080P:2048kbps/3072kbps/4096kbps/5120kbps/6144kbps
Audio
Audio input/output
Built-in MIC input/Bluetooth device output;
Compression
G.726
Record
Storage
Support 2pcs SD
Format
FAT32
Record strategy
Default power-on record,also support alarm record and
events trigger record,manual record
PTZ
Zoom
20X/30X
IR Distance
>60 meters
Protocol
Pelco D/P
Speed
360”rotation; 120”/s
Vertical speed
-15°-90° vertical: 60°/S
Preset position
200
3G/4G/WIFI
Support 3G/4G and compatible with GPRS,EDGE, etc; built-in
WIFI,Support hot spot configuration
GPS(option)
Support GPS, option/BD/GLONASS
Firmware upgrading
SD card; remotely upgrade
Power supply
Battery
Built-in battery, daytime mode working time;about 15hours;night
vison mode working tine;
about 10 hours;extemal power supply;19V3.34A
Battery Usage
display
OLED displays are displayed in real time
Work Environment
Temperature
-25℃ ~ +60℃
Humidity
10% ~ 95%
Installation
Installation(option)
Sucker installation ; Fixed chassis installation(option);
able-elevated bracket installation(option)
Waterproof grade
IP66
Size
170(W) x 1607(H) x 170(D) mm(with bracket installation)
170(W) x 277(H) x 170(D) mm(No bracket installation)
